Safe and reliable: 1. Two-way safety steering, four-level safety brake protection, safer driving; 2. Electric braking + electric braking + drum braking, to meet the needs of long-distance heavy downhill conditions of slow running; 3. Power battery active and passive thermal management, mature chassis to ensure quality.
Green environmental protection: 1. Zero emissions; 2. Low noise.
Economic comfort: 1. Less maintenance supplies, low cost; 2. Fine control strategy, driving energy saving, efficient recovery; 3. Automatic transmission without power interruption in all working conditions, simple operation and easy driving.
Intelligent network connection: 1. Standard intelligent network connection and diagnosis system; 2. All-weather vehicle fault self-diagnosis, monitoring and operation.
Strong power: 1. Double motor drive, sufficient climbing power; 2. Fast start and high operating speed.
Main technical parameters
|
item |
Parameter/configuration |
|
|
Model number |
YZJ105 |
YZJ105A |
|
Dynamic form |
Pure electric |
Pure electric |
|
Rated load mass (t) |
70 |
68 |
|
Maximum total mass (t) |
105 |
105 |
|
Front/rear axle load (t) |
25+40+40 |
25+40+40 |
|
Outer dimension (mm) |
9960*3750*4200 |
9960*3750*4200 |
|
Container capacity (m³) |
40 |
40 |
|
Drive motor (kw) (rated/peak) |
545/800 |
545/800 |
|
gearbox |
Four speed AMT |
Four speed AMT |
|
Maximum speed (km/h) |
45 |
45 |
|
Maximum gradient (%) |
35 |
35 |
|
Power Battery (kwh) |
396 |
528 |
|
Battery charge time (h) |
≤1.2 |
≤1.2 |
|
Suspension structure |
Front hydro-pneumatic suspension/rear leaf spring |
Front hydro-pneumatic suspension/rear leaf spring |
|
Steering form |
Full hydraulic + emergency steering |
Full hydraulic + emergency steering |
