Intelligent and efficient: 1. Full electronic control system, more efficient; 2. Full working condition boom intelligent buffer system, more reliable; 3. Intelligent anti-skid system, more secure.
Green environmental protection: 1. Zero emissions; 2. Low noise.
Economic comfort: 1. Less maintenance supplies, low cost; 2. Double motor more energy saving; 3. Manual self integrated transmission, simple operation, easy to drive.
Intelligent network connection: 1. Standard intelligent network connection and diagnosis system; 2. All-weather vehicle fault self-diagnosis, monitoring and operation.
Strong power: 1. Two independent motors for walking and working; 2. Shovel material, climb slope, pile material power.
Main technical parameters
|
type |
Product name | 6T | 5T | 3T |
|
Machine parameter |
Product model |
YZJ968EV |
YZJ958EV |
YZJ938EV |
|
Length * Width * Height (mm) |
9240*3160*3480 |
8290*3100*3450 |
7600*2500*3350 |
|
|
Rated power (Kw) |
245 |
180 |
98 |
|
|
Rated load mass (t) |
6.8 |
5.8 |
3.8 |
|
|
Quality of Work (t) |
23 |
18 |
11 |
|
|
Bucket capacity (m³) |
3.6-5.5 |
2.7-4.5 |
1.7-2.5 |
|
|
Power battery |
Rated capacity (Kwh) |
350/423 |
282/350 |
180 |
|
Battery life (h) |
6-8 |
|||
|
Drive motor |
Motor power (kW) |
140/240 |
100/200 |
50/100 |
|
Working motor |
Motor power (kW) |
105/180 |
80/160 |
48/92 |
|
gearbox |
Speed ratio (2 gears) |
2.8/1 |
2.5/1 |
2.5/1 |
|
type |
Hands in one AMT |
|||
|
其他配置 |
Job control system |
Fully electronically controlled intelligent control |
||
|
Working hydraulic system |
Two-pump confluence |
|||
|
Steering hydraulic system |
Full hydraulic steering |
|||
|
Service brake system |
Full hydraulic braking |
|||
|
Parking brake system |
Oil cutoff brake |
|||
|
Intelligent control |
Boom cushioning, intelligent shovel loading |
|||
|
air conditioner |
Integrated heating and cooling air conditioning is standard |
|||
